| model | BCM95720A2003AC |
| Lifecycle | Active |
| Max Speed |
5GT/s |
|
Connector Type
|
RJ45 |
| Warranty | 3 Years |
מודל :
BCM95720A2003ACמק"ט :
BCM95720A2003ACסוג חבילה :
Cartonגודל חבילה יחיד :
26*20*8 CMמשקל ברוטו יחיד :
0.54 KGמינימום הזמנה :
1 Pieceמשלוח :
Contact supplier to negotiate shipping detailsתשלומים :
Western Union、L/C、T/T、MoneyGram、D/A、D/Pהחזרות והחזרים כספיים :
Returns & refunds acceptאחריות :
3 Years1、 Basic hardware information: Complete model: BCM95720A2003AC. Main control chip: Broadcom BCM5720 (13th generation NetXtreme Gigabit Server Controller, single-chip integrated dual MAC+dual PHY). Host bus: PCIe 2.1 x1, speed 5GT/s; Compatible with PCIe 1.0/2.0 x1/x4/x8/x16 slots. Board size: MD2 half height Low Profile standard card, standard with full height metal blocking plate, no original half height blocking plate. Heat dissipation: Small passive aluminum heat sink, fanless. Power consumption: Typical full load ≤ 5W, PCIe 3.3V/12V power supply. Product positioning: Dual gigabit Ethernet card for enterprise servers, universal for virtualization, soft routing, and storage business intranet. 2、 Port and transmission parameters: Port: 2 x RJ45 10/100/1000BASE-T adaptive electrical port. Rate negotiation: 1000M/100M/10M full/half duplex automatic switching. Cable standard: Cat5e and above twisted pair, maximum 100 meters. Jumbo Frame: Supports Jumbo Frame 9000 bytes. Flow control: IEEE 802.3x full duplex flow control, EEE energy-saving Ethernet 802.3az low-power mode. Port indicator light: Each RJ45 is equipped with 2 LEDs.
Key Features
| Model | BCM95720A2003AC |
| Form Factor | PCI-E Card |
| Interface (Bus) Type |
PCIe 2.1 x1 |
| Network Interface | 5GT/s |
| Bracket height | Full height/Half height |
| Ports |
Dual port RJ45 |
Lead time
| Quantity (pieces) | 1-10 | 10-60 | >60 |
| Lead time (days) | 3 | 3-5 | To be negotiated |
