| model | MCX353A-QCBT |
| Lifecycle | Active |
| Max Speed |
10GbE |
|
Connector Type
|
QSFP+ |
| Warranty | 3 Years |
מודל :
MCX353A-QCBTמק"ט :
MCX353A-QCBTסוג חבילה :
Cartonגודל חבילה יחיד :
26*20*8 CMמשקל ברוטו יחיד :
0.54 KGמינימום הזמנה :
1 Pieceמשלוח :
Contact supplier to negotiate shipping detailsתשלומים :
Western Union、L/C、T/T、MoneyGram、D/A、D/Pהחזרות והחזרים כספיים :
Returns & refunds acceptאחריות :
3 YearsController and Bus: Controller: ConnectX-3. Bus: PCIe 3.0 x8, 8GT/s, backward compatible with PCIe 2.0/1.1. Port information: Number of ports: 1 x QSFP+. Protocol mode: VPI (ports can independently switch between InfiniBand/Ethernet). IB mode: QDR 40Gb/s InfiniBand. Ethernet mode: up to 10GbE, native firmware cannot support 40GbE. Heat dissipation and baffle: Heat dissipation method: active heat dissipation (equipped with a small heat dissipation fan). Standard configuration: Full height baffle with half height baffle included. Core functional features: RDMA: RoCE v1, native InfiniBand RDMA. Virtualization: SRIOV, up to 127 VFs; VMQ, NetQueue. Hardware uninstallation: TCP/UDP checksum LSO、LRO、 Giant frames. VXLAN/NVGRE hardware uninstallation is not supported. Supports PCIe network boot GPU Direct RDMA。 IB mode MPI ping delay<1 μ s. Operating system compatibility: Linux, Windows Server, VMware SQLite, FreeBSD.
Key Features
| Model | MCX353A-QCBT |
| Form Factor | PCI-E Card |
| Interface (Bus) Type |
PCIe 3.0 x8 |
| Network Interface | 10GbE |
| Bracket height | Full height/Half height |
| Ports |
Single port QSFP+ |
Lead time
| Quantity (pieces) | 1-10 | 10-60 | >60 |
| Lead time (days) | 3 | 3-5 | To be negotiated |
